Vessel detail id: A547

For Charter

US$ 11,500,000

PRINCIPAL CHARACTERISTICS


Id: A547
Categories: Oil Tanker
Class: NJTS
Length: 115.00 Meters
Breadth: 17.60 Meters
Depth: 8.70 Meters
Net Tonnage: None
Gross Tonnage: None
Deadweight: 7000



Country Built: China
Condition: New
Sale: Yes Charter: No




Description:
7,000 DWT DOUBLE HULL PRODUCT OIL TANKERS(Cargo Pump Room Type)
LOADING CAPACITIES
Deadweight at design draught, mld (SW) Abt 7000tons
Cargo tanks capacity (98% full) incl. slop tanks # abt. 7900m3
Slop tank capacity (98% full) abt. 165 m3
Fuel oil tanks capacity # abt. 300 m3
Marine diesel oil tank Abt 75 m3
Fresh water tanks capacity abt. 190 m3
Water ballast tank incl. F.P.T. & F.B.T. abt. 2820m3
MAIN ENGINE AND GENERATOR
Main Engine
Main engine 8N330
Number of set 1 set
Max. continuous output (MCR) 3310 kw
Max. continuous revolutions at MCR 620 rpm
Continuous service Rating (CSR) 1 x 2813 kw
Propeller
Type FPP
Number of set 1 set
Material of propeller Ni-Al-Bronze
No. of Blades 5
Main generator set
No. of set & power
Electric source
2 sets x 280 kw+ x 1800rpm
A.C. three phases, 440V, 60Hz.
Emergency generator set
No. of set & power 1 set x 90 kw x 1800 rpm
Electric source




ADDED: Jan. 31, 2012 MODIFIED: Jan. 31, 2012
